? The series has a variety of colours. For example red, yellow, yellowgreen, blue and so on.
? Applies to Pb-free reflow soldering;
? Green product, Complied with ROHS directive
? The product is generally used as indicator, shcu as module display of household appliances, motormeter and so on.
| Parameter | Symbol | Rating |
| Forward Current | IF | 60mA |
|
Pulse Forwards Current*2 |
IFP | 100mA |
|
Reverse Voltage |
VR |
5V |
|
Working Temperature |
TOPR |
-30~+85℃ |
|
Storage Temperature |
TSTG |
-40~+100℃ |
? pulse-width≤0.1ms，duty-factor≤1/10
| Part number | Color |
I F( mA) TEST |
λD ( nm) / XY Typ |
I V( mcd) Typ. |
VF( V) Typ. |
VF( V) Max |
|
FFM- T5050HRK- 624N |
Red | 60 | 624 | 2400 | 2.0 | 2.4 |
|
FM- T5050HYK- 589N |
Yellow | 60 |
592 |
2500 |
2.0 |
2.4 |
|
FM- T5050UGK- 520D |
Green | 60 |
525 |
4300 |
3.0 |
3.6 |
|
FM- T5050BK- 470M |
Blue | 60 | 470 | 1400 |
3.0 |
3.6 |
