· The chip is directly placed on aluminum PCB.
·Universal dimension，cost-effective.
·Applicable to downlight，spot light， street light etc.
·Rated power：3-7w.
Part number |
Color Temp（K）
|
CRI Ra Min |
Φv（l m）
Typ. |
IF TEST(mA) | Voltage（V） |
Max power
（W）
|
|
MC-H1215CW-3W0350302 |
6500 | 80 |
340-380 |
350 | 8. 5-10. 5 |
4 |
|
MC-H1215NW-3W0350302 |
4000 | 80 |
340-370 |
350 |
8. 5-10. 5 |
4 |
|
MC-H1215WW-3W0350302 |
3000 | 80 |
340-335 |
350 |
8. 5-10. 5 |
4 |
|
MC-H1215CW-5W0350502 |
6500 | 80 |
570-630 |
350 |
14. 5-17. 5 |
6.5 |
|
MC-H1215NW-5W0350502 |
4000 |
80 |
550-610 |
350 |
14. 5-17. 5 |
6.5 |
|
MC-H1215WW-5W0350502 |
3000 |
80 |
520-580 |
350 |
14. 5-17. 5 |
6.5 |
|
MC-H1215CW-7W0151201 |
6500 |
80 |
600-660 |
150 |
34. 5-42 |
8 |
|
MC-H1215NW-7W0151201 |
4000 |
80 |
565-625 |
150 |
34. 5-42 |
8 |
|
MC-H1215WW-7W0151201 |
13000 | 80 |
530-590 |
150 |
34. 5-42 |
8 |
