①Integrated Matrix Device (IMD) solution, smaller pixel pitch, higher definition image display.
②Integrated Matrix Device (IMD) solution, smaller pins, solve the problems of soldering strength and crash.
③High precision cutting technology, solve the problems of warping and mixed light in display, achieve to the seamless combination
④Gold wire bonding, better reliability.
⑤Reduce the effect of moore grain, no modular color difference in whole screen, 100% tested and binning, better color consistency.
Product Name |
Color |
IF(mA) TEST |
λd(nm) Typ |
Iv(mcd) Typ |
Vf(V) Typ |
View angle (deg.) |
IMD-M09T
|
5 | 620 | 15 | 2.0 | 120 | |
| 2 | 535 | 25 | 2.6 | 120 | ||
| 2 | 464 | 3.5 | 2.7 | 120 |
