1.Bending inside of leadframe, multiple waterproof and high reliability；
2.White leadframe, high brightness, low power consumption, ink spray on 5 surfaces to improve contrast;
3.High luminous surface and low PINs height, convenient for glue filling and mask installation；
4.Independent PINs for R/G/B, free design for common cathode or common anode.
Product Name | Color |
IF(mA) TEST |
λd(nm) Typ |
Iv(mcd) Typ |
Vf(V) Typ |
View angle (deg.) |
NH-Z1415RGBA-SG | 20 | 622 | 680 | 2.2 | 110 | |
| 20 | 520 | 1350 | 3.2 | 110 | ||
| 20 | 469 | 270 | 3.3 | 110 |
